4K UHD Medical Video Recorder - ACCEL VM500

2021/01/28

Medical Video Recorder

Full HD or 4K video recording - ACCEL VM500

Multiple video input interface for Full HD or 4K video recording

Onyx Medical recorder support Full HD recording with different legacy video input interface including YPbPR, CVBS, DVI or S-Video and 4K Video recording with HDMI input

  • Full UHD 60Hz input: YPbPR, CVBS, DVI,  S-Video and 3G SDI
  • Recording video resolution : 1920 x 1080p 60/50fps
  • 4K UHD 60Hz iutput: HDMI 2.0
  • Recording video resolution :4096x2160p 60/50Hz
  • 4K UHD or Full HD recorded/captured files: H.264



Medical certification

Medical certification

Onyx recording system certifies with UL60601-1, IEC60601-1 and FCC Part 18







SDK Provide

SDK Provide

Onyx can provide SDK for the system integrator to do the integration with existing infrastructure







Multiple storage support

Multiple storage support

Support 2 x 2.5” HDD or SSD and 1 x M.2 NVMe SSD.









Onyx version recording software

Onyx version recording software

Onyx also can provide Onyx version recording software including the features below

  • Patient data entry and archiving
  • Video playback, copy and preview
  • Video timeline tag and editing
  • Snapshot of the video as a picture to save
  • When two or more Capture Cards are detected, it will automatically switch to Dual Mode
